Madell CT-859 Desoldering Station
Price:$155.00
This Temp-controlled desoldering station is composed of: an air pump part,
a heating part, a transfer part, and a control part. The air pump part
includes a diaphragm pump and a high power electro electro motor. The heating
part is a ceramic heater(temperature sensor) & desoldering tip. The
transfer part is made up of a desoldering gun, a vacuum pippette, and a
filter gauge. Control part is control PCB. While working, the electromotor
drives air pump and make negative pressure to imbibe melted soldering tin
into filter pipe, thereby it suctions out soldering tin onto the circuit
board.
Packing List
- CT-859 Desoldering Station
- Accessories to CT-859 (4 desoldering tips, cleaning rod, filter, etc.)
- Soldering Stand
- Operational Manual
- Power Cord
|
Specifications:
- Anti-static design prevents damage caused by static and creepage.
- Powerful built-in vacuum pump doesn't require connection to another vaccuum
system.
- Heating system is an adopted sensor that uses closed loop temperature control
to ensure precision and constant temperature.
- Transformer makes the power from the main power supply into 26V AC low
voltage for the heating element, ensuring safety.
- High quality hot-resistant soft vacuum tube, to avoid damage by hot desoldering
gum.
- Electromotor of vacuum pump is temperature safe, preventing damage due
to long use.
|
Features:
Power Supply Voltage |
110±10%V AC 60Hz |
Heating Power |
60W/27 ± 10% AC 60Hz |
Desoldering Tip Temperature |
280°C-450°C |
Pump |
Diaphragm |
Vacuum Suction |
-680mmHg |
Tip to Ground Resistance |
Less than 2Ohm |
Electromotor Power |
40W/110V AC |
Tip to Ground Potention |
Less than 2mV |
Dimension |
105x250x165mm |
Weight |
About 4kg w/ iron holder & power cord |
\
Madell QK201B ESD Desoldering Station
Specifications:
- Vacuum pump power: 80W/110VDC.
- Heating power: 60W/36VAC.
- Tip temperature: 320°C-480°C.
- Digital display
- Pump: Diaphragm.
- Vacuum pressure: 600mmHg.
- Tip to ground resistance: <2 ohm.
- Tip to ground potential: <2mv.
- Dimension: 105x250x165mm.
- One year warranty.
Price:$245.00
Improved model over QK201A, specifications the same.
|
|
|
Name
|
Price
|
|
A1004(small), 0.8mm |
$12.00
|
|
A1005(medium), 1.0mm |
$13.00
|
|
A1006(large), 1.3mm
|
$14.00
|
|
|
|
|
|
